Brand: AOFA Machinery
If you're buying heavy-duty this is certainly reliable to address your construction tasks, AOFA Machinery's LW600FN Wheel Loader Model may be the solution that is perfect your requirements. Fashioned with state-of-the-art technology, this product delivers energy that is exceptional efficiency that guarantees top performance in most task.
The LW600FN Wheel Loader Model are designed for almost any heavy lifting and load-carrying task with simplicity featuring its durable and construction that is robust. The apparatus includes an optimum loading capacity as high as 6 tons, which makes it your decision that is ideal heavy-duty construction work. This revolutionary product delivers optimal results whether you're loading and unloading materials on location, moving planet, or concentrating on a mining website.
The most known options that come with the LW600FN Wheel Loader Model is its system that is efficient that hydraulic. The equipment that is built that is hydraulic work similarly with the motor, providing maximum energy transfer and performance. This feature ensures that these devices operate steadily and effortlessly with minimal fuel consumption, making it an acceptable and choice that is eco-friendly.
With regards to navigating through challenging terrains, the LW600FN Wheel Loader Model is unmatched. The gear can tackle terrains with simplicity featuring its versatile and adjustable wheel system. The adjustable wheels may be set to twin, solitary, and steering this is certainly tight, depending on the surface and load need. The device's automated transmission system also assures maneuverability that is smooth rough surfaces.
The LW600FN Wheel Loader Model was made to give maximum operator convenience and safety. The operator's cabin is spacious, air-conditioned, and fitted with ergonomic seats for optimum comfort. The cabin was created to cut back noise and vibration, supplying operators with a comfy and place of work this is certainly safe. The operator can easily control and adjust the gear's functions from a display that is solitary improving safety into the place of work utilizing the cabin's higher rate control system.
It is the preferential machinery product in the fields of ports, and engineering constructions.
1.The super-strong heavy-duty structural parts, enhanced drive system, and globally supplied critical parts can carry the torsion and impact loads under diversified working conditions.
2.The high energy-conservation and high-efficiency hydraulic system is applied to realize higher
fuel utilization efficiency and more powerful working capacity.
3.The strong breakout force of 205KN ensure that the machine could adapt to various tough condition.
4.Heavy load for the rocky condition; the working device and front and rear frame feature thick
board of high strength, reasonable distribution and strong carrying capacity.
5.The large rock bucket with capacity of 3-4.5m³ is improved in terms of the work efficiency and adaptation.
|
Description |
Unit |
Parameter value |
|
Rated operating load |
kg |
6000 |
|
Bucket capacity |
m³ |
3.0～4.5 |
|
Machine weight |
kg |
20000±300 |
|
Dump clearance at maximum lift |
mm |
3170～3750 |
|
Reach at maximum lift |
mm |
1200～1360 |
|
Wheel base |
mm |
3350 |
|
Tread |
mm |
2265 |
|
Max.breakout force |
kN |
205 |
|
Max.horse power |
kN |
174 |
|
Hydraulic cycle time-raise |
s |
≤5.9 |
|
Total hydraulic cycle time |
s |
≤10.9 |
|
Min. turning radius over tyres |
mm |
6005 |
|
Articulation angle |
° |
38 |
|
Gradeability |
° |
28 |
|
Tyre size |
23.5-25 |
|
|
Overall machine dimension L×W×H |
mm |
8505×3220×3515 |
|
Rated Power |
kW |
178 |
|
Fuel Tank |
L |
250 |
|
Hydraulic Tank |
L |
210 |
|
Travel Speed |
km/h |
6-34 |
